930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module

Certification : ISO

Brand Name : OEM

Place of Origin : China

MOQ : 1 Piece

Price : Negotiable

Payment Terms : T/T,PayPal,Negotiable

Packaging Details : Standard Package

Delivery Time : 1-3 Working Days

Supply Ability : 10000 Sets / Month

Model NO. : PF-AM091

Condition : New

Support Network : All

Information Content : All

Product Name : RF GaN Power Amplifier Module

Frequency : 930-1020MHz

Output Power : 100W

Gain : 47dBm

Voltage : 24-32V

Product Weight : 183G

Intra-Band Fluctuations : ≤2.5 (Peak-to-Peak Value)

in-Band Group Delay : ≤1us

Input Voltage Standing Wave Ratio : ≤1.35

Transport Package : Carton

Specification : 37.3*112*19.5mm

Trademark : No

Origin : Guangdong, China

Contact Now

930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module
Padi Fly main business includes UAV detector module, handheld detection, backpack detection, vehicle detection, UAV accessories, etc.


Product Description


930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module
Product Parameters


Appearance and installation instructions:
1. Overall dimensions: 170*94*26.5mm
2. Interface form:
Power supply conditions: +30V power supply: 7W2 (male)
RF input interface: SMA-KFD (optional)
RF output interface: N-KFD
Control interface:
a.7W2 (male) socket: The first pin is connected to the power amplifier enable PA_SW (high level 5V/3.3V power amplifier turns on,low level or floating, the power amplifier turns off)
b.Feedthrough capacitor: From top to bottom, they are SRC_SW (internal signal source switch 5V/3.3V on, floating or grounded signal source off), PS_SW (internal and external signal source switch, low level is the built-in source, high level Level 5V/3.3V switch to external source)
3.Mounting hole diameter: Leave 4 Φ4.5mm through holes at the mounting holes for mounting M3 screws.

Brand Name
PDFY
Working frequency
930-1020MHz
Power
50W
Supply Voltage
DC 24-32V
Max Output Power
47 dBm
Working Efficiency
≥60%
Passband Riplpe
≤2dB
Weight
105 g
Operating Temperature
-10~+55ºC
Power supply requirements
≥3.7A
RF Connector
SMA
Weight
183g
Size
37.3*112*19.5mm (Excluding SMA)
Connect line red
DC28-30V
Connect line black
GND
Connect line white
ENABLE
Detailed Photos
930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module
930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module
Company Profile


930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module

Padi Fly Technology Co. Ltd specializes in the field of advanced technology.

Our company is located in the vibrantcity of Shenzhen,known as a hub of innovation andtechnology in China.
With over 3000 square meters of plant space, we specialize in the design, development, and distribution of FPV drones along with drone countermeasure solution.
We are known for our innovation, quality, and commitment to enhancing the user experience.

930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module930-1020MHz 50W GaN Anti Drone Module for Anti Drone System Autel Anti Fpv C-Uas Mavic 3 Autel Fpv RF Module

Our Business Range for FPV drone accessories:
We can provide include: Image transmission, motor, carbon fiber frame, flight control, electrical regulation, antenna, remote control, propeller, charger, etc..

We also provide the industry's professional OEM and ODM technology and services.
